P7MAIN/CDi3.P7/CDi3.LE Boardsets Available To/Through SCi.RS Members Only, "Offshore" and "Marine" need not apply
The SingleChips International Research Society (SCi.RS) which holds the technology through its founders will soon form the commercial arm of the society, the singlechips.IKE company, which will be a mostly fabless company that may choose from time to time to fabricate a product to level A, B, or C as shown below. XYZ is an outfit made up of SCi.RS members operating at a different location, XYZ may choose to source from singlechips.IKE as little as a parts list and some blank (unpopulated) boards, although it is more likely, initially at least, to source product in a more advanced state of completion. In the specific submersible example below the monthly software authorization charges of 9oz Ag/m for simple flowmeters and 14oz Ag/m for switching controllers apply and are the same regardless of the state of completion of source devices. For land use, discount all prices by 50%. The slideshows at page bottom show more general examples of system use. Pricing in maples Ag.
Level A, 225oz Ag + (9oz Ag/m or 14oz Ag/m)
Level B, 337oz Ag + (9oz Ag/m or 14oz Ag/m)
Level C, 450oz Ag + (9oz Ag/m or 14oz Ag/m)
Submersible Natural Gas Digital Flow Meters/Production Controllers
There are three different hardware platforms, affectionately known around here as:
CDi3s.FTe, CorvetteI in a typical 3-TR submersible flow meter application.
CDi3s.FTe, CorvetteI in a 3-TR digital submersible plunger lift application.
CDi3s.FTe, CorvetteI in a 3-TR digital submersible plunger lift application. [+]
Capability: Upstream, downstream flow recording, timed and smart switching.
Firmware: 3sMF6704:0000, SRC
CDi3s.FTe, CorvetteI in a 3-TR digital submersible flow meter application. [+]
Capability: Upstream, downstream and casing flow recording only, no switching.
Firmware: 3sMF6701:0000, SRC
CDi3s.FTe, CorvetteI in a typical 2-TR submersible flow meter application.
CDi3s.FTe, CorvetteI in a 2-TR digital submersible flow meter application. [+]
Capability: Upstream, downstream flow recording only, no switching.
Firmware: 3sMF6700:0000, SRC
CDi3s.FTe, CorvetteI in a typical 1-TR digital submersible plunger lift application.
CDi3s.FTe, CorvetteI in a 1-TR digital submersible plunger lift application. [+]
Capability: Timed switching only,
cannot record flow.
Firmware: 3sMF6702:0000, SRC
  • The CorvetteI (CDi3s) which can be built by assembling new P7MAIN boardsets originally designed in 2010,
  • The CorvetteII(CDi3t) which can be built by assembling new CDi3.P7 boardsets designed in 2016, and,
  • The Ferrari (CDi3f) which can be built by assembling new CDi3.LE boardsets designed in 2016.

    One box, five functions, two flow meters and three switchers, arranged and numbered in increasing complexity from 0 to 4.

  • CDi3s.FTe, CorvetteI in a typical 2-TR digital submersible plunger lift application.
    CDi3s.FTe, CorvetteI in a 2-TR digital submersible plunger lift application. [+]
    Capability: Upstream, downstream flow recording and some smart switching.
    Firmware: 3sMF6703:0000, SRC
    TR = TRansmitter = PA10 series RS485 digital pressure transmitter, supplied by Keller in Switzerland. These are state-of-art devices, silicone oil isolated, with Hastelloy C276 stainless wetted parts. The company allows its clients to buy just the essentials and thus subsequently design and build their own housings. Only one type of pressure transmitter to stock!
    Boardset Availability

    Availability
    Assembly
    Nickname
    Boardset
    Future Start Max
    Board On Time
    Batt. Chem./Capacity
    RTC
    Battery Life
    6
    CDi3s.FTe.*6Z
    1.5 Days
    2.1 Seconds
    DS1386
    14.3 Years
    2f + 8pf
    CDi3t.FTe.*6Z
    0
    CDi3f.FTe.*3Z
    30 Days
    1.2 Seconds
    DS1553
    23.6 Years

    Current Stock, CorvetteI Boards
    6 New CorvetteI Boards Available (P7MAIN).
    Completion Level: 100% Click [+]
    Current Stock, CorvetteII  Boards
    2 Finished + 8 Unfinished New CorvetteII Boards Available (CDi3.P7). These can use the DS1553 RTC and become Ferraris or use the DS1386 RTC and become CorvetteIIs. Unfinished Completion level: 65% Click [+]
    Past/Present/Future
    Download .pptx
    Download .pdf
    Download .odp
